Siemens launches digitalized aspirating smoke detectors suited for large protection areas

Siemens launches digitalized aspirating smoke detectors suited for large protection areas

Two new aspirating smoke detectors, FDA261 and FDA262, extend the existing fire detection portfolio

  • Particularly suited for critical infrastructure and very large protection areas
  • Highly intuitive commissioning app and improved detection performance
  • Modular design to prolong lifetime and reduce environmental footprint.

Siemens has introduced two new aspirating smoke detectors (ASD), FDA261 and FDA262, catering to particularly challenging fire safety installations that extend over wide areas, such as large data centers, e-commerce warehouses, or industrial manufacturing sites. A single device can cover up to 6,700 m², currently the largest coverage area available on the market. Even for Class A installations with the highest sensitivity requirements, up to 2,000 m² of detection coverage is feasible with a single ASD+ detector.

The new ASD Connect app ensures fast and easy digital commissioning. It makes the commissioning process highly automated and intuitive. As a result, the commissioning effort decreases significantly.

ASD safeguards megatrends

“ASD plays a crucial role in protecting the infrastructure needed to enable global megatrends, such as the energy transition or digitalization. One example is fire protection for the rapidly growing number of lithium-ion battery energy storage systems,” said Peter Nebiker, Head of Fire Safety at Siemens Smart Infrastructure.

The new ASD+ fully integrates in fire safety systems from Siemens, communicating directly and intelligently as addressable device using the Siemens FDnet/C-NET, without additional hardware cost or wiring for I/O cards. This reduces the time and effort needed for installation while enabling data transmission to the panel and remote locations, such as the cloud.

High performance in any environment

ASD+ offers better detection performance and maximum immunity to false alarms. Along with high standards for detection sensitivity, the detection optics hardware has been optimized for harsh and dirty environments. The dual-wavelength signal processing algorithm has been improved to reliably differentiate between smoke particles and dust, thus avoiding the risk of false alarms. ASD+ products have adjustable alarm thresholds (0,003 to 20%/m), providing complete flexibility to meet the needs of any application. Additional information such as pre-alarm, dust detection or contamination-level reporting adds value for customers and can be accessed via the Siemens cloud portal.

Reflecting Siemens’ dedication to sustainability throughout the product lifecycle, the new products follow a modular design, allowing the detection chamber and aspirator to be easily replaced without reconfiguration.

Produse mentionate in articol
Detector de fum cu aspiratie Siemens FDA262

Detector de fum cu aspiratie Siemens FDA262

Detector de fum cu aspiratie cu doua camere. Extinderea ofertei Siemens de protectie impotriva incendiilor cu o noua generatie de detectoare de fum cu aspiratie (ASD+). Noul si cel mai puternic ASD+ combina doua sisteme independente de aspirare a fumului intr-un singur dispozitiv si permite monitorizarea incaperilor de pana la 6700 m², respectiv 3000 m² (Clasa A). Aplicatia ASD Connect accepta punerea in functiune si intretinerea rapida si fara fir. Atunci cand este conectat la o centrala de alarma de incendiu Siemens cu gateway, este asigurat si transferul de date in cloud. Aceasta inseamna ca informatiile importante sunt disponibile in orice moment si simplifica planificarea tintita a lucrarilor de service si reparatii. Datorita designului modular, componentele cheie precum camera de detectare si aspiratorul pot fi inlocuite cu usurinta, ceea ce creste durata de viata a produselor, reduce amprenta de carbon si tine cont de interesele economice ale clientilor.

Brosura
Vezi detalii
Card produs
Detector de fum cu aspiratie Siemens FDA261

Detector de fum cu aspiratie Siemens FDA261

Extinderea ofertei Siemens de protectie impotriva incendiilor cu o noua generatie de detectoare de fum cu aspiratie (ASD+). Noul si cel mai puternic ASD+ combina doua sisteme independente de aspiratie a fumului intr-un singur dispozitiv si permite monitorizarea incaperilor de pana la 3600 m², respectiv 2000 m² (Clasa A). Aplicatia ASD Connect accepta punerea in functiune si intretinerea rapida si fara fir. Atunci cand este conectat la o centrala de alarma de incendiu Siemens cu gateway, este asigurat si transferul de date in cloud. Aceasta inseamna ca informatiile importante sunt disponibile in orice moment si simplifica planificarea tintita a lucrarilor de service si reparatii. Datorita designului modular, componentele cheie precum camera de detectare si aspiratorul pot fi inlocuite cu usurinta, ceea ce creste durata de viata a produselor, reduce amprenta de carbon si tine cont de interesele economice ale clientilor.

Brosura
Vezi detalii
Card produs
